Lightning Surge Simulator (LSS) Isolation Transformer MODEL : TF-6503P
Model TF-6503P is three-phase isolation transformer rated AC 600 V / 50 A and dielectric strength of 4 kV. For safety reasons, an isolation transformer is indispensable for AC powered testing for equipment.
Specifications
| Parameter | Specifications |
|---|---|
| Maximum input voltage | Single / Three phase AC 600 V Max (50/60 Hz) |
| Transformer wiring method | Star wiring |
| Maximum output current | 50 A Max |
| Dielectric strength | Primary winding to core AC 4 kV (1 minute) Secondary winding to core AC 4 kV (1 minute) Primary to secondary windings AC 4 kV (1 minute) |
| Insulation resistance | 100 MΩ or more at DC 500 V |
| Dimensions / Weight | (W)500 x (H)640 x (D)700mm (Eye bolts and handles excluded) approx. 350kg |
| Accessories | AC three-phase line input cable (14sq 4-line 3m, One end: with a stick-type soldering terminal, the other end: without terminal):1 pc. PE cable (8sq 3m, One end: with a φ6 ring-type soldering terminal, The other end: without terminal): 1 pc. PE/FG cable (8sq 3m Both ends: with a φ6 ring-type soldering terminal): 1 pc. Instruction Manual: 1 pc. AC three phase line output cable (14sq 4-line 2m, One end: with stick-type soldering terminal, The other end: with a φ5 ring-type soldering terminal): 1pc. PE cable (8sq 2m, One end: with a φ6 ring-type soldering terminal, The other end: with a φ5 ring-type soldering terminal): 1pc. |
