Isolation Transformer MODEL : TF-2302P
Model TF-2302P is a single-phase isolation transformer rated AC240V/30A with dielectric strength of 4kV.
For safety reasons, an isolation transformer is indispensable for AC powered testing for equipment.
Specifications
| Parameter | Specifications |
|---|---|
| Maximum input voltage | Single phase AC240V Max (50/60Hz) |
| Maximum output current | 30A Max |
| Dielectric strength | Primary winding to core AC4kV (1 minute) Secondary winding to core AC4kV (1 minute) Primary to secondary windings AC4kV (1 minute) |
| Insulation resistance | 100MΩ or more at DC500V |
| Dimensions / Weight | (W)350 x (H)475 x (D)400mm (Except for eye bolt and handle) / Approx. 60kg |
| Accessories | AC single phase line input cable (5.5sq 3-line 3m, One end: with a stick-type soldering terminal, The other end: without terminal): 1pc., PE/FG cable (3.5sq 3m Both ends: with a φ6 ring-type soldering terminal) : 1pc. Instruction Manual: 1pc. AC single phase line output cable (3.5sq 3-line 2m, One end: with stick-type soldering terminal, The other end: with a φ5 ring-type soldering terminal): 1pc. |
